Vaned Expansion Brass Insert

Vaned Expansion Brass Insert
Vaned Expansion Brass Insert
Product Code : DBI-034
Brand Name : Dutux
Product Description

Brass Vaned Expansion Brass Inserts

Thread
Size

Length
(L)

ØD

Pilot Hole

M2

4.0

3.7

3.2

M2.5

5.8

4.5

4.0

M3

5.8

4.5

4.0

M4

8.2

6.2

5.6

M5

9.5

6.9

6.4

M6

12.7

8.5

8.0

M8

12.7

10.1

9.6

All dimensions in mm.
Pilot hole dimensions are for reference purposes only.



Brand Name : dutux



Brass Vaned Expansion Insert Metal : Brass / Copper Alloy



Brass Vaned Expansion Insert Rod : Casting / Extrusion



Brass Vaned Expansion Insert Material :

Free Cutting Brass IS 319 Type (l)

Free Cutting Brass as per BS 249 Type (I)

Generally Free Machine Grade of CuZn37Pb3 equivalent to BS 2874 is used to manufacture various brass threaded inserts in form of round, Hexagon, Square etc

Other grades which are followed as per custom requirements are CZ 121, CZ 131, C3604, CDA 360, and DTD 627 etc

High Grade Free Cutting Brass.

Any Special Brass Material Composition as per customer’s requirement



Brass Vaned Expansion Insert Threads :

ISO Metric (MM Threads)

BA Threads

BSW Threads (Inches)

UNC, UNF,UNEF and NPT Threads

BSP & BSPT (Parallel & Taper Threads)

Any threads as per specifications



Brass Vaned Expansion Insert Finishing & Coating :

Natural

Golden Finish

Silver Finish

Nickle Platted

Chrome Platted

Tin Plated

Any coating as per customer specifications



Brass Vaned Expansion Insert Packing Details :

Bag Packging,

Innear Plastic Packing,

Carton Packaging,

Woodan Carton Packing



Brass Vaned Expansion Insert Special Features :

Thread as per international Go and Not Go Gauge Standard.

Deep Groove for maximum Pull out Resistance.

Inner Diameter (ID) after threading with very close tolerance to prevent unrequired flush to enter into brass inserts.



Brass Vaned Expansion Insert Application :

Plastic Industries

Furniture Industry

Electronic Industry

Automobile Industry,etc...



Brass Vaned Expansion Insert MOQ : 1000 Pieces



Brass Vaned Expansion Insert Lead Time : 3 Working Days



Brass Vaned Expansion Insert Available Price :

EX-Work

FOB - Free On Board

C&F - Cost And Freight

CIF  - Cost, Insurance and Freight

Specialized in Brass Inserts
