Brass Slot Drive Insert

Brass Slot Drive Insert

110 INR/Pack

Product Details:

  • Material Brass
  • Usage Automobile
  • Color Golden
  • Type BRASS INSERTS
  • CNC Machining Yes
  • Diameter 1 Millimeter (mm)
  • Tolerance 0.02 Millimeter (mm)
  • Click to View more
X

Brass Slot Drive Insert Price And Quantity

  • 110 INR/Pack
  • 1000 Pack

Brass Slot Drive Insert Product Specifications

  • Automobile
  • 0.02 Millimeter (mm)
  • Other
  • Other
  • Golden
  • Brass
  • BRASS INSERTS
  • Yes
  • NO
  • 1 Millimeter (mm)

Brass Slot Drive Insert Trade Information

  • JNPT,NAHVA SEHVA,MUNDRA
  • 200000 Pack Per Day
  • 30 Days
  • Yes
  • Contact us for information regarding our sample policy
  • As per customer required
  • All India
  • ISO 2009:2015

Product Description



Having both customers and quality centric approach, we are engrossed in manufacturing, exporting and supplying a wide array of Brass Slot Drive Insert. This insert is manufactured using quality assured brass by our ingenious professionals. Widely demanded in petrochemicals and pharmaceutical sectors, this insert is highly demanded to make threaded holes. Our valued clients can buy this Brass Slot Drive Insert from us at the most affordable rate.

Key Points:

  • High durability
  • Firm grip
  • Dimensional accuracy
  • Corrosion resistance

Brass Slot Drive Insert

Thread
Size

Available Lengths (L)

D

Pilot Hole

M3

6 / 8 / 10 / 12

6.0

4.6-5.2

M4

8 / 10 / 12 / 15

8.0

5.7-6.6

M5

10 / 12 / 15 / 20

10.0

7.6-8.5

M6

10 / 12 / 15 / 18 / 20 / 25 / 30

12.0

9.4-10.4

M8

15 / 18

14.0

12.6-14.0

M8

14 / 18 / 23 / 30

16.0

12.6-14.0

M10

15 / 20 / 25 / 30 / 40

18.5

15.1-16.5

M12

20 / 25 / 30 / 35

22.0

18.3-19.8

M16

25 / 30 / 35

25.0

21.3-22.8

M20

30

30.0

26.3-27.8

With fully threaded internal length.
All dimensions in mm.
Pilot hole dimensions are for reference purposes only.

Brand Name : dutux

Metal: Brass / Copper Alloy

Brass Slot Drive InsertRod : Casting / Extrusion

Material:
  • Free Cutting Brass IS 319 Type (l)
  • Free Cutting Brass as per BS 249 Type(I)
  • Generally Free Machine Grade of CuZn37Pb3 equivalent to BS 2874 is used to manufacture various brass threaded inserts in form of round, Hexagon, Square etc
  • Other grades which are followed as per custom requirements are CZ 121, CZ 131, C3604, CDA 360, and DTD 627 etc
  • High Grade Free Cutting Brass.
  • Any Special Brass Material Composition as per customers requirement
Brass Slot Drive InsertThreads:
  • ISO Metric (MM Threads)
  • BA Threads
  • BSW Threads (Inches)
  • UNC, UNF,UNEF and NPT Threads
  • BSP & BSPT (Parallel & Taper Threads)
  • Any threads as per specifications
Finishing & Coating:
  • Natural
  • Golden Finish
  • Silver Finish
  • Nickle Platted
  • Chrome Platted
  • Tin Plated
  • Any coating as per customer specifications
Packing Details :
  • Bag Packging,
  • Innear Plastic Packing,
  • Carton Packaging,
  • Woodan Carton Packing
Special Features :
  • Thread as per international Go and Not Go Gauge Standard.
  • Deep Groove for maximum Pull out Resistance.
  • Inner Diameter (ID) after threading with very close tolerance to prevent unrequired flush to enter into brass inserts.
Application:
  • Plastic Industires
  • Furniture Industry
  • Electronic Industry
  • Automobile Industry,etc...

MOQ : 1000 Pieces

Brass Slot Drive InsertLead Time : 3 Working Days

Available Price :

  • EX-Work
  • FOB - Free On Board
  • C&F - Cost And Freight
  • CIF - Cost, Insurance and Freight

Specialized in Brass Inserts

Product details

  • Available Lengths : 30
  • Model Number : DBI-024
  • Pilot Hole : 26.3-27.8
  • Thread Size : M20
  • Diameter : 30
  • Usage/Application : Pipe Fitting
  • Brand : Dutux



FAQs of Brass Slot Drive Insert:


Q: Is the Brass Slot Drive Insert suitable for CNC machining?

A: Yes, it is suitable for CNC machining.

Q: What is the tolerance level of the Brass Slot Drive Insert?

A: The tolerance level of the Brass Slot Drive Insert is 0.02mm.

Q: What is the material of the Brass Slot Drive Insert?

A: The material of the Brass Slot Drive Insert is brass.

Q: What is the diameter of the Brass Slot Drive Insert?

A: The diameter of the Brass Slot Drive Insert is 1mm.
