Unheaded Screw-In Brass Insert

Unheaded Screw-In Brass Insert
Unheaded Screw-In Brass Insert
Product Code : DBI-033
Brand Name : Dutux
Product Description

Brass Unheaded Screw In Brass Inserts

Thread
Size

Available
Lengths (L)

ØD

Pilot Hole

M2

4.0 / 4.8

3.5

3.1-3.3

M2.5

4.0 / 5.25 / 6.25

4.33

3.8-4.1

M3

4.0 / 5.25 / 6.25

4.73

4.1-4.4

M3.5

5.0 / 6.2 / 7.3

5.52

5.0-5.3

M4

5.6 / 7.1 / 8.4

6.31

5.8-6.1

M5

6.4 / 8.4 / 10.0

7.5

6.9-7.2

M6

7.9 / 9.8 / 12.0

8.69

8.0-8.4

M8

9.5 / 12.4

11.06

10.1-10.6

M10

12.0 / 16.0

13.95

13.0-13.5

All dimensions in mm.
Pilot hole dimensions are for reference purposes only.



Brand Name : dutux



Brass Unheaded Screw-in Insert Metal : Brass / Copper Alloy



Brass Unheaded Screw-in Insert Rod : Casting / Extrusion



Brass Unheaded Screw-in Insert Material :

Free Cutting Brass IS 319 Type (l)

Free Cutting Brass as per BS 249 Type (I)

Generally Free Machine Grade of CuZn37Pb3 equivalent to BS 2874 is used to manufacture various brass threaded inserts in form of round, Hexagon, Square etc

Other grades which are followed as per custom requirements are CZ 121, CZ 131, C3604, CDA 360, and DTD 627 etc

High Grade Free Cutting Brass.

Any Special Brass Material Composition as per customer’s requirement



Brass Unheaded Screw-in Insert Threads :

ISO Metric (MM Threads)

BA Threads

BSW Threads (Inches)

UNC, UNF,UNEF and NPT Threads

BSP & BSPT (Parallel & Taper Threads)

Any threads as per specifications



Brass Unheaded Screw-in Insert Finishing & Coating :

Natural

Golden Finish

Silver Finish

Nickle Platted

Chrome Platted

Tin Plated

Any coating as per customer specifications



Brass Unheaded Screw-in Insert Packing Details :

Bag Packing,

Inner Plastic Packing,

Carton Packaging,

Wooden Carton Packing



Brass Unheaded Screw-in Insert Special Features :

Thread as per international Go and Not Go Gauge Standard.

Deep Groove for maximum Pull out Resistance.

Inner Diameter (ID) after threading with very close tolerance to prevent unrequired flush to enter into brass inserts.



Brass Unheaded Screw-in Insert Application :

Plastic Industries

Furniture Industry

Electronic Industry

Automobile Industry,etc...



Brass Unheaded Screw-in Insert MOQ : 1000 Pieces



Brass Unheaded Screw-in Insert Lead Time : 3 Working Days



Brass Unheaded Screw-in Insert Available Price :

EX-Work

FOB - Free On Board

C&F - Cost And Freight

CIF  - Cost, Insurance and Freight
