Brass Studded Press In Insert

Brass Studded Press In Insert
Brass Studded Press In Insert
Product Code : DBI-028
Brand Name : Dutux
Trade Information
  • Minimum Order Quantity
  • 100
  • Unit of Measure
  • Piece/Pieces
  • FOB Port
  • Jamnagar - Gujarat
  • Payment Terms
  • Cheque, Others
  • Supply Ability
  • 2000 Pieces Per Month
  • Delivery Time
  • 30 Days
  • Sample Available
  • Yes
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • Standard Packaging
  • Main Domestic Market
  • Gujarat
Product Description

Since our incorporation in the year 2002, we have been indulged in manufacturing, exporting and supplying Brass Studded Press In Insert. This insert is manufactured using top-notch quality brass materials by our dexterous professionals at our sophisticated production unit. Provided insert is widely demanded in many industries for fastening purposes. Additionally, this Brass Studded Press In Insert can be purchased from us at nominal rates.


Key Points:

  • Excellent finish
  • Corrosion proof
  • Rigid construction
  • Durable design



Brass Studded Press In Inserts

Thread
Size

Length
(L)

ØH

ØD

T

Pilot Hole

M2

4.0

4.8

3.35

0.6

3.1

M2.5

5.3

5.6

4.4

0.6

3.8

M3

5.3

5.6

4.2

0.6

4.2

M3.5

6.3

6.4

5.0

0.8

4.6

M4

7.4

7.2

5.8

0.8

5.4

M5

8.3

8.0

6.6

1.0

6.2

M6

9.2

9.5

8.2

1.3

7.8

M8

9.2

11.0

9.7

1.3

9.3

All dimensions in mm.

Pilot hole dimensions are for reference purposes only.

Available with or without head, and with a stud length (S) of 6, 10, 16 or 25mm

Brand Name : dutux

Metal :Brass / Copper Alloy

Brass Studded Press-in Insert Rod : Casting / Extrusion

Material :

Free Cutting Brass IS 319 Type (l)

Free Cutting Brass as per BS 249 Type (I)

Generally Free Machine Grade of CuZn37Pb3 equivalent to BS 2874 is used to manufacture various brass threaded inserts in form of round, Hexagon, Square etc

Other grades which are followed as per custom requirements are CZ 121, CZ 131, C3604, CDA 360, and DTD 627 etc

High Grade Free Cutting Brass.

Any Special Brass Material Composition as per customer’s requirement

Brass Studded Press in Insert Threads :

ISO Metric (MM Threads)

BA Threads

BSW Threads (Inches)

UNC, UNF,UNEF and NPT Threads

BSP & BSPT (Parallel & Taper Threads)

Any threads as per specifications

Finishing & Coating :

Natural

Golden Finish

Silver Finish

Nickle Platted

Chrome Platted

Tin Plated

Any coating as per customer specifications

Packing Details :

Bag Packging,

Innear Plastic Packing,

Carton Packaging,

Woodan Carton Packing

Special Features :

Thread as per international Go and Not Go Gauge Standard.

Deep Groove for maximum Pull out Resistance.

Inner Diameter (ID) after threading with very close tolerance to prevent unrequired flush to enter into brass inserts.

Application :

Studded insert suitable for heated or cold press-in installation into plastics.

Plastic Industires

Furniture Industry

Electronic Industry

Automobile Industry,etc...

Brass Studded Press-in Insert MOQ :1000 Pieces

Brass Studded Press-in Insert Lead Time :3 Working Days

Brass Studded Press-in Insert Available Price :

EX-Work

FOB - Free On Board

C&F - Cost And Freight

CIF  - Cost, Insurance and Freight

 Specialized in Brass Inserts
